P3
3 in 1 Panel Controller (RGB/RGBW/RGB+CCT)

• Compatible with Mi-Light / MiBoxer 2.4GHz series remote
• Widely used on the controlling of single color LED strips, panel lights,etc
• High precision Capacitive touch screen IC
• Tempered glass panel

Model No.: P3 Category:
3 in 1 Panel Controller (RGB/RGBW/RGB+CCT)

Widely used on the controlling of Single Color, CCT, RGB, RGBW and RGB+CCT LED strips, panel lights,etc

Product Parameters
Product Name

3 in 1 Panel Controller (RGB/RGBW/RGB+CCT)

Model No.

P3

Input Voltage

DC12V-24V

Output

5A/Channel

Total Output

Max 10A

RF

2.4GHz

Control Distance

30m

IP Rate

Working Temperature

-20~60°C

Connection

Common anode



Simple but multi-functional

Easy installation, safe and reliable

60S Delay OFF

Contextual Mode

LED Night indicating lamp

Sensitive Touching

Scratch Resistance

Compatiable with RGB / RGBW / and RGB+CCT LED strip

Switching RGB,RGBW and RGB+CCT version randomly

Switch to RGB mode: When the Light is OFF, Long press “ Mode ” and “ W ” button at the same time, The controller will sound 3 times after 5seconds.

Switch to RGBW mode: When the Light is OFF, Long press “ W ” and “ 60S Delay OFF ” button at the same time, The controller will sound 4 times after 5seconds.

Switch to RGB+CCT mode: When the Light is OFF, Long press “ Mode ” and “ 60S Delay OFF ” button at the same time, The controller will sound 5 times after 5seconds.

2.4GHz RF Remote control (Control distance 30m)
16 Millions of colors to choose
Saturation adjustable, meet the diversified lighting
Color temperature adjustable
Brightness adjustable, smooth transition without flicker

Compatible with the following remotes

PWM high frequency / low frequency

High frequency / low frequency can be switched

Support smartphone app control and third party voice control (It need 2.4GHz gateway)
60S Delay OFF

 Lamps will be off automatically after 60 seconds

Night Light Guidance Function

LED indicating lamp on the ON/OFF button; Let you find the switch easily on dark night.

Sensitive touching

High precision Capacitive touch screen IC Touch Screen is very stable

12 Dynamic model

decorate any ambient lighting for you

Tempered glass panel

Scratching and crushing resistance

Touching button with sound

When touching the button, LED indicating lamp will flash once with different sound

PC Housing

Adopt high-end PC housing with best quality

Installation / Dismantlement
Method of installation

1. Install the bottom case into the wall; Above are the standard bottom cases.

2. Fix the controller base on the bottom case with screw.

3. Clicks into the upper side of glass panel on the controller base, then press the lower side slightly to make it clicks into the controller base.

Installation Overview
Method of dismantlement

Plug into the below bayonet with a screwdriver, and upwarp screwdriver, then you can dismantle the controller.

Product Name

3 in 1 Panel Controller (RGB/RGBW/RGB+CCT)

Model No.

P3

Input Voltage

DC12V-24V

Output

5A/Channel

Total Output

Max 10A

RF

2.4GHz

Control Distance

30m

IP Rate

Working Temperature

-20~60°C

Connection

Common anode

User Manual
