Widely used on the controlling of single color LED strips, panel lights,etc
| Product Name | Panel Controller (Single Color) |
|---|---|
| Model No. | P1 |
| Input Voltage | DC12V-24V |
| Output | 5A/Channel |
| Total Output | Max 10A |
| RF | 2.4GHz |
| Control Distance | 30m |
| IP Rate | – |
| Working Temperature | -20~60°C |
| Connection | Common anode |
Easy installation, safe and reliable
Brightness Dimming
60S Delay OFF
Contextual Mode
LED Night indicating lamp
Sensitive Touching
Scratch Resistance
Compatible with the following remotes
High frequency / low frequency can be switched
Lamps will be off automatically after 60 seconds
Dimming(1~100%) the light randomly
LED indicating lamp on the ON/OFF button; Let you find the switch easily on dark night.
High precision Capacitive touch screen IC Touch Screen is very stable
decorate any ambient lighting for you
Scratching and crushing resistance
When touching the button, LED indicating lamp will flash once with different sound
Adopt high-end PC housing with best quality
1. Install the bottom case into the wall; Above are the standard bottom cases.
2. Fix the controller base on the bottom case with screw.
3. Clicks into the upper side of glass panel on the controller base, then press the lower side slightly to make it clicks into the controller base.
Plug into the below bayonet with a screwdriver, and upwarp screwdriver, then you can dismantle the controller.
