Home » Products » FUT074ZR 6W RGB+CCT LED Downlight (Zigbee 3.0 + 2.4GHz)

FUT074ZR
6W RGB+CCT LED Downlight (Zigbee 3.0 + 2.4GHz)

• Product follow zigbee 3.0 standard protocol
• Zigbee Contrl distance: 100m (open area)
• Compatible with Mi-Light / MiBoxer 2.4GHz series remote
• 2.4G RF Remote Control Distance: 30m
• 16 Millions of colors to choose
• Color temperature and brightness adjustable

Available Downloads:
Manual

Model No.: FUT074ZR Category:

Out of stock

6W RGB+CCT LED Downlight (Zigbee 3.0 + 2.4G)

Built-in power / Transmitting & Synchronization / 16million colors / Adjustable saturation CCT & Brightness

Product Parameters
Product Name

6W RGB+CCT LED Downlight (Zigbee 3.0 + 2.4GHz)

Model No.

FUT074ZR

Input Voltage

100-240V~ 50/60Hz

Power

6W

PF

0.5

CRI

>80

Color Temperature

3000K-6500K

Luminous Flux

560LM

Luminous Efficiency

93LM/W

Beam Angle

120°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 100m (open area)
2.4G RF Remote: 30m

IP Rate

Working Temperature

-10~40°C

HoIe Size

ø90-95mm

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz

Switch Color Temperature Manually

Toggle the switch left and right to select different color temperature

No Flicker Care For Eye Health

Energy-saving and comfortable home lighting

PA6 Material

Good heat and wear resistance, more stable in use

2.4GHz RF Remote control (Control distance 30m)
16 Millions of colors to choose
Saturation adjustable, meet the diversified lighting
Color temperature adjustable
Brightness adjustable, smooth transition without flicker

Compatible with the following remotes

Signal transmitting

One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.

Modes synchronization

Different lighting fixtures can work synchronously when they are started at different times, controlled by the same remote, under same dynamic mode and within 30m distance.

Lighting Fixtures
Signal transmitting & Modes synchronization
Distance 30m
Lighting Fixtures
. . .
[Tuya Smart] APP control
Need to match Zigbee 3.0 gateway to experience more functions (Zigbee 3.0 gateway needs to be purchased separately)

Scene customization​

Music rhythm

Do not disturb mode

Timing setting

Device sharing

Tap-to-Run & automation

Music rhythm function

The Lamp will automatically change color along with music

Group Control

Group control control can be achieved through the mobile app

Support third party voice control
Need to be equipped with Zigbee 3.0 gateway(needs to be purchased separately), which can control ON/OFF, brightness, colors, etc. through voice.
It can enter into Philips Hue, IKEA TRADFRI, Amazon ECHO Plus ( 2nd Gen), ECHO (4th Gen), ECHO Studio, ECHO Show (2. Gen) standard Zigbee 3.0 gateway.
Support DMX512 Controllable

Need DMX512 LED transmitter

Product Name

6W RGB+CCT LED Downlight (Zigbee 3.0 + 2.4GHz)

Model No.

FUT074ZR

Input Voltage

100-240V~ 50/60Hz

Power

6W

PF

0.5

CRI

>80

Color Temperature

3000K-6500K

Luminous Flux

560LM

Luminous Efficiency

93LM/W

Beam Angle

120°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 100m (open area)
2.4G RF Remote: 30m

IP Rate

Working Temperature

-10~40°C

HoIe Size

ø90-95mm

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz
