Follow Zigbee 3.0 standard protocol, Support Music rhythm and 2.4GHz Remote control
| Product Name | 5 in 1 LED Strip Controller (Zigbee 3.0 +2.4G) |
|---|---|
| Model No. | ZL5 |
| Input Voltage | DC12~48V |
| Output | 6A/Channel |
| Total Output | Max 15A |
| Communication Protocol | Zigbee 3.0 + 2.4GHz |
| Control Distance | Zigbee: 100m (open area) |
| IP Rate | – |
| Working Temperature | -10~40°C |
| Wireless Technology | Zigbee 802.15.4 |
| Wireless Frequency | 2.400-2.480GHz |
Single Color \ Dual White \ RGB \ RGBW \ RGB+CCT
Compatible with the following remotes
Need to match Zigbee 3.0 gateway to experience more functions (Zigbee 3.0 gateway needs to be purchased separately)
Scene customization
Music rhythm
Do not disturb mode
Timing setting
Device sharing
Tap-to-Run & automation
High frequency / low frequency can be switched
One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.
Different lighting fixtures can work synchronously when they are started at different times, controlled by the same remote, under same dynamic mode and within 30m distance.
Only for RGB+CCT output mode, Need DMX512 LED transmitter
