FUT103ZR
4W GU10 RGB+CCT LED Spotlight (Zigbee 3.0 + 2.4G)

• Product follow zigbee 3.0 standard protocol
• Zigbee Contrl distance: 50m (open area)
• Compatible with Mi-Light / MiBoxer 2.4GHz series remote
• 2.4G RF Remote Control Distance: 30m
• 16 Millions of colors to choose
• Brightness and color temperature adjustable

Available Downloads:
Manual

4W GU10 RGB+CCT LED Spotlight (Zigbee 3.0 + 2.4G)

Product follow zigbee 3.0 standard protocol. Match Zigbee 3.0 gateway to experience more functions

Product Parameters
Product Name

4W GU10 RGB+CCT LED Spotlight (Zigbee 3.0 + 2.4G)

Model No.

FUT103ZR

Input Voltage

100-240V~ 50/60Hz

Power

4W

PF

>0.55

CRI

>80

Color Temperature

2700K~6500K

Luminous Flux

320LM

Luminous Efficiency

80LM/W

Beam Angle

25°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 50m (open area)
2.4G RF Remote: 30m

IP Rate

Working Temperature

-10~40°C

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz

Base Type

GU10

2.4GHz RF Remote control (Control distance 30m)
16 Millions of colors to choose
Saturation adjustable, meet the diversified lighting
Color temperature adjustable
Brightness adjustable, smooth transition without flicker

Compatible with the following remotes

Signal transmitting

One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.

Modes synchronization

Different lighting fixtures can work synchronously when they are started at different times, controlled by the same remote, under same dynamic mode and within 30m distance.

Lighting Fixtures
Signal transmitting & Modes synchronization
Distance 30m
Lighting Fixtures
. . .
[Tuya Smart] APP control
Need to match Zigbee 3.0 gateway to experience more functions (Zigbee 3.0 gateway needs to be purchased separately)

Scene customization​

Music rhythm

Do not disturb mode

Timing setting

Device sharing

Tap-to-Run & automation

Support third party voice control
Need to be equipped with Zigbee 3.0 gateway(needs to be purchased separately), which can control ON/OFF, brightness, colors, etc. through voice.
It can enter into Philips Hue, IKEA TRADFRI, Amazon ECHO Plus ( 2nd Gen), ECHO (4th Gen), ECHO Studio, ECHO Show (2. Gen) standard Zigbee 3.0 gateway.
Support DMX512 Controllable

Need DMX512 LED transmitter

Acrylic Transmitting Cover

Using imported PC pervious to light cover, light transmittance over 90%

High lumen LED Chips

Low power consumption and luminance decrease; Bright color and high brightness

Product Name

4W GU10 RGB+CCT LED Spotlight (Zigbee 3.0 + 2.4G)

Model No.

FUT103ZR

Input Voltage

100-240V~ 50/60Hz

Power

4W

PF

>0.55

CRI

>80

Color Temperature

2700K~6500K

Luminous Flux

320LM

Luminous Efficiency

80LM/W

Beam Angle

25°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 50m (open area)
2.4G RF Remote: 30m

IP Rate

Working Temperature

-10~40°C

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz

Base Type

GU10
