WL5-WP
Waterproof 5 in 1 LED Strip Controller (WiFi+2.4GHz)

• Support third party voice control (Alexa, Google Assistant)
• 2.4G RF Remote controllable
• 16 Millions of colors to choose
• Color temperature adjustable
• Brightness and saturation controllable
• Switching 5 output mode via one button (Single color / Dual white / RGB / RGBW / RGB+CCT)

Available Downloads:
Manual

SKU WL5-WP Categories ,
WL5-WP
Waterproof 5 in 1 LED Strip Controller (WiFi+2.4GHz)

Product Description

Waterproof 5 in 1 LED Strip Controller (WiFi+2.4G)

Compatible with Single Color, CCT, RGB, RGBW and RGB+CCT output mode. Signal transmitting & Mode synchronization

Product Parameters
Product Name

Waterproof 5 in 1 LED Strip Controller (WiFi+2.4G)

Model No.

WL5-WP

Input Voltage

DC12~36V

Output

6A/Channel

Total Output

Max 20A

Communication Protocol

WiFi+2.4G

2.4G RF Control Distance

30m

IP Rate

IP67

Working Temperature

-20~45°C

WiFi Standard

IEEE 802.11b/g/n 2.4GHz

2.4GHz RF Remote control (Control distance 30m)
16 Millions of colors to choose
Saturation adjustable, meet the diversified lighting
Color temperature adjustable
Brightness adjustable, smooth transition without flicker
Signal transmitting

One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.

Modes synchronization

Different lighting fixtures can work synchronously when they are started at different times, controlled by the same remote, under same dynamic mode and within 30m distance.

Lighting Fixtures
Signal transmitting & Modes synchronization
Distance 30m
Lighting Fixtures
. . .
Support smartphone app control and third party voice control

No need 2.4GHz gateway, directly control

IP67 waterproof rating

Waterproof design, eliminates potential safety hazards and makes use safer

Product Parameters

Product Name

Waterproof 5 in 1 LED Strip Controller (WiFi+2.4G)

Model No.

WL5-WP

Input Voltage

DC12~36V

Output

6A/Channel

Total Output

Max 20A

Communication Protocol

WiFi+2.4GHz

2.4G RF Control Distance

30m

IP Rate

IP67

Working Temperature

-20~45°C

WiFi Standard

IEEE 802.11b/g/n 2.4GHz
