Home » Products » FUTC02ZR 9W RGB+CCT LED Garden Light (Zigbee 3.0 + 2.4G)

FUTC02ZR
9W RGB+CCT LED Garden Light (Zigbee 3.0 + 2.4G)

• Product follow zigbee 3.0 standard protocol
• Zigbee Contrl distance: 50m (open area)
• Compatible with Mi-Light / MiBoxer 2.4GHz series remote
• 2.4G RF Remote Control Distance: 30m
• 16 Millions of colors to choose
• Brightness and color temperature adjustable

Available Downloads:
Manual

9W RGB+CCT LED Garden Light (Zigbee 3.0 + 2.4G)

Product follow zigbee 3.0 standard protocol. Match Zigbee 3.0 gateway to experience more functions

Product Parameters
Product Name

9W RGB+CCT LED Garden Light (Zigbee 3.0 + 2.4G)

Model No.

FUTC02ZR

Input Voltage

100-240V~ 50/60Hz

Power

9W

PF

>0.5

CRI

>80

Color Temperature

2700K~6500K

Luminous Flux

900LM

Luminous Efficiency

100LM/W

Beam Angle

15°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 50m (open area)
2.4G RF Remote: 30m

IP Rate

IP66

Working Temperature

-20~45°C

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz

Illumination Distance

>10m

2.4GHz RF Remote control (Control distance 30m)
16 Millions of colors to choose
Saturation adjustable, meet the diversified lighting
Color temperature adjustable
Brightness adjustable, smooth transition without flicker

Compatible with the following remotes

Signal transmitting

One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.

Modes synchronization

Different lighting fixtures can work synchronously when they are started at different times, controlled by the same remote, under same dynamic mode and within 30m distance.

Lighting Fixtures
Signal transmitting & Modes synchronization
Distance 30m
Lighting Fixtures
. . .
[Tuya Smart] APP control
Need to match Zigbee 3.0 gateway to experience more functions (Zigbee 3.0 gateway needs to be purchased separately)

Scene customization​

Music rhythm

Do not disturb mode

Timing setting

Device sharing

Tap-to-Run & automation

Support third party voice control
Need to be equipped with Zigbee 3.0 gateway(needs to be purchased separately), which can control ON/OFF, brightness, colors, etc. through voice.
It can enter into Philips Hue, IKEA TRADFRI, Amazon ECHO Plus ( 2nd Gen), ECHO (4th Gen), ECHO Studio, ECHO Show (2. Gen) standard Zigbee 3.0 gateway.
Support DMX512 Controllable

Need DMX512 LED transmitter

waterproof and ventilation valve

Balance differential pressure inside and outside Avoid condensation inside the lamp

High efficiency heat dissipation

Integrative Aluminum design Inserted thermal conduction Protect light source lifespan

Anti Corrosion inserted pole

Barb design, longer and bigger

Product Name

9W RGB+CCT LED Garden Light (Zigbee 3.0 + 2.4G)

Model No.

FUTC02ZR

Input Voltage

100-240V~ 50/60Hz

Power

9W

PF

>0.5

CRI

>80

Color Temperature

2700K~6500K

Luminous Flux

900LM

Luminous Efficiency

100LM/W

Beam Angle

15°

Communication Protocol

Zigbee 3.0 + 2.4GHz

Control Distance

Zigbee: 50m (open area)
2.4G RF Remote: 30m

IP Rate

IP66

Working Temperature

-20~45°C

Wireless Technology

Zigbee 802.15.4

Wireless Frequency

2.400-2.480GHz

Illumination Distance

>10m
