Product Description
9W RGB+CCT LED Garden Light (Subordinate Lamp)
Wireless Remote Controlling by connecting the “Host Controller”
Product Parameters
| Product Name | 9W RGB+CCT LED Garden Light (Subordinate Lamp) |
|---|---|
| Model No. | SYS-RC1 |
| Input Voltage | DC24V |
| Power | 9W |
| PF | – |
| CRI | >80 |
| Color Temperature | 2700K~6500K |
| Luminous Flux | 900LM |
| Luminous Efficiency | 100LM/W |
| Beam Angle | 15° |
| Communication Protocol | SYS Host Control |
| IP Rate | IP66 |
| Working Temperature | -20~45℃ |
| Illumination Distance | >10m |
Connection Diagram
Note: When using “Host controller”, you need to add “1-channel signal amplifier” for below 3 situations.
1. Connecting over 50pcs lights
2. Connected cable length over 300m
3. Output power over 360W
